BreezSlim SLM50-100LED Ventilation Fan – 50/80/100 CFM Fan/Dimmable LED Light w/ High Speed Adjustable (coming soon!)
Home / Products / Slim Series / SLM50-100LED
- ENERGY STAR® qualified with innovative brushless DC motor technology
- Full speed adjustable, 50CFM, 80CFM, or 100CFM
- Perfectly quiet operation 0.9 sones at 100 CFM @ 0.1"SP
- Constant airflow upto 100 CFM @ 0.4"SP
- Energy efficiency is 8.0 CFM/Watt at 100CFM
- Low profile housing with a 3-3/8“ depth fits in a 2"x4” wall
- UL approved for ceiling and wall mount installation
- Flat cover enhances the modern aesthetic
- Two Duct adapter installation options available: inside-out or outside-in
- 13W Dimmable LED light output 850 lumens, 3000K and 90CRI, less than 1W night light. Dimmer switch not included
- LED indicator will be green when power is on
- Annual energy cost for 24/7 operation is approximately $6.21* (@50 CFM), $9.80* (@80 CFM), $14.94* (@100 CFM) *Calculations based upon U.S. average retail electricity and HVI testing labs. Actual results may vary.
Super Low Profile. Super Low Energy Consumption.
The ventilation fan shall be the Delta Breez model SLM50-100LED, qualified under ENERGY STAR® and equipped with a high‑efficiency brushless DC motor designed for continuous operation for a minimum of 70,000 hours. The fan shall deliver an airflow of 100 CFM with a maximum sound level of 0.9 sones at 0.1" static pressure, as certified by the Home Ventilating Institute (HVI). Power consumption shall not exceed 12.5 watts, providing an efficiency rating of 8.0 CFM/W at 0.1" static pressure. The unit shall include motor lock protection and feature self‑compensating motor speed to maintain the specified airflow under varying static pressure conditions. UL and cUL listed for tub/shower enclosure when used with GFCI-protected branch circuit wiring.
SLM50-100LED - 50/80/100 CFM Exhaust Fan/Dimmable LED Light
| Fan Speed | Full Speed | ||||||||
| Static Pressure (inches w.g.) | 0.1 | 0.25 | 0.375 | 0.1 | 0.25 | 0.375 | 0.1 | 0.25 | 0.375 |
| Air Flow (CFM) | 50 | 50 | 50 | 80 | 80 | 80 | 100 | 100 | 100 |
| Sones | <0.3 | 0.7 | - | 0.4 | 1.0 | - | 0.9 | 1.4 | - |
| Power Consumption (Watts) | 5.2 | 8.2 | 12.0 | 8.2 | 12.8 | 17.2 | 12.5 | 17.4 | 22.1 |
| Energy Efficiency (CFM/Watts) | 9.6 | 6.1 | 4.2 | 9.7 | 6.2 | 4.6 | 8.0 | 5.7 | 4.5 |
| Current (Amps) | 0.6 Max | ||||||||
| Power Rating (V/Hz) | 120 / 60 | ||||||||
| Dimmable LED Light (Watts) | 13 | ||||||||
Digital Files for Revit Users
For the convenience of the Architectural and Engineering professionals who rely on quality BIM content to deliver their projects, Delta Breez offers powerful functionality in our easy to use Revit Families (.rfa’s). Download them today for free.
Families Include:
• Accurately Modeled Geometry
• Revit Electrical Connector
• Revit Duct Connector
• Type Catalogs Files (.txt) for small file size.
• Face-Hosted for Easy Placement.
